EN10025-2 S235JR steel

s235jr is a kind of low alloy steel under EN10025 standard. The impact test is at room temperature .S235JR steel has the proper tensile strength, good toughness, plasticity, processing property, be rolled into steel plates, shaped steel and profile steel, which usually used to build workshop, bridge, vessels and so on.



EN10025-2 S235JR Chemical Composition

Grade	Chemical Composition
S235JR	The Element Max (%)
	C			Si	Mn	P	S	N	Cu
	≤16	＞16≤40	＞40
	0.19	0.19	0.23	-	1.50	0.045	0.045	0.014	0.60

EN10025-2 S235JR Mechanical Property

Grade	Mechanical Property
S235JR	Yield Strength mm Min Mpa									Tensile Strength mm Min Mpa
	≤16	＞16 ≤ 40	＞40 ≤ 63	＞63 ≤ 80	＞80 ≤ 100	＞100 ≤ 150	＞150 ≤ 200	＞200 ≤ 250	＞250 ≤ 400	＜3	≥ 3 ≤ 100	＞100 ≤ 150	＞150 ≤ 250	＞250 ≤ 400
	235	225	215	215	215	195	185	175	-	360-510	360-510	350-500	340-490	-

S235JR is a grade under the Europe standard 10025-2. In the brand S235JR, S is the symbol for Structural Steel and JR for 20 temperature impac test, and a minimum yield strength of 235 N/mm²which can be widely used in the engineering and construction.

S235 material can be supplied in S235JR, S235J0, S235J2. The verification of the impact energy value should be carried out in accordance with EN 10025-1.
